LIFT OPERATING SYSTEM FOR WHEEL TURNING LATHES UBB-112 (UBB-112F3), UBB-112/2, UBB-112/2RG AND THEIR MODIFICATIONS

No; Spare part; Quantity;Note; ;

1; Compensating ring;1;; Order link=#rec477264474 2; Dip stick;1;; Order link=#rec477264474 3; Cover;1;; Order link=#rec477264474 4; Washer;2;; Order link=#rec477264474 5; Shaft;1;L=640mm; Order link=#rec477264474 6; Flange;1;D=110mm, L=52mm; Order link=#rec477264474 7; Plug;1;; Order link=#rec477264474 8; Pipe ;1;L=140mm, d=13,5mm;Order link=#rec477264474 9; Spacer;2;;Order link=#rec477264474 10; Worm gear;1;d=77mm, L=50mm, m=4,⠀z=16;Order link=#rec477264474 11; Housing;1;;Order link=#rec477264474 12; Cover ;1;D=100mm;Order link=#rec477264474 13; Nut;1;;Order link=#rec477264474 14; Bushing;1;D=85mm, d=62mm, L=32mm;Order link=#rec477264474 15; Worm;1;L=205mm, m=4,⠀z=2;Order link=#rec477264474 16; Clutch ;1;D=58mm, L=40mm;Order link=#rec477264474 17; Clutch;1;D=78m, L=75mm;Order link=#rec477264474 18; Flange;1;D=250mm, d=140mm, L=22mm;Order link=#rec477264474
