SPINDLE STOCK FOR WHEEL TURNING LATHES RT905F3, RT905F1 AND THEIR MODIFICATIONS

VIEW 1 and VIEW 2

No	Spare part	Quantity	Note

1	Faceplate	1	d=1050mm, L=275mm	Order
2	Screw	6	L=130mm	Order
3	Cover	1	D=335mm, L=12mm	Order
4	Nut	1	D=120mm, L=22mm	Order
5	Center	1		Order
6	Quill	1	d=240mm, L=815mm	Order
7	Spindle	1	Flange⠀d=500mm, L=1184mm	Order
8	Flange	1	D=590mm, L=28mm	Order
9	Cover	3		Order
10	Ring	1	D=1132mm, L=30mm	Order
11	Shaft	1	L=630mm	Order
12	Gear	1	d=230mm, L=135mm, m=10,⠀z=20	Order
13	Gear	1	d=426mm, L=137mm, m=6,⠀z=69	Order
14	Gear	1	d=380mm, L=85mm, m=5,⠀z=74	Order
15	Gear	1	d=162mm, L=110mm, m=6,⠀z=25	Order
16	Spacer	2	D=90mm, L=15mm	Order
17	Shaft	1	d=80mm, L=326mm	Order
18	Housing	1		Order
19	Gear	1	d=150mm, L=85mm, m=5,⠀z=28	Order
20	Shaft	1	L=427mm	Order
21	Cover	1		Order
22	Half clutch	1	D=250mm, L=100mm	Order
23	Half clutch	1	D=250mm, L=100mm	Order
24	Cover	1	d=170mm, L=23mm	Order
25	Compensator	1	D=140mm, L=7mm	Order
26	Cover	1		Order
27	Compensator	1	D=190mm, L=15mm	Order
28	Bushing	2	D=145mm, L=45mm	Order
29	Compensator	1	d=190mm, L=6mm	Order
30	Bushing	1	D=365mm, L=200mm	Order
31	Nut	1	D=450mm, L=60mm	Order
32	Plate	1		Order
33	Flange	1		Order
34	Bushing	1	D=160mm, L=110mm	Order
35	Nut	1	D=50mm, L=90mm, Tr⠀60x8	Order
36	Drip pan	1		Order
37	Filter strainer	1		Order
38	Bosh	1		Order
39	Collector	1	90x65x40mm	Order
40	Cover	1		Order
41	Pad	1	220x40x25mm	Order
42	Screw	1		Order
43	Strip	1	200x50x12mm	Order
44	Bracket	1		Order
45	Strip	4	L=160mm	Order
46	Strip	4	L=160mm	Order
47	Scraper	4	L=160mm	Order
48	Insert	1		Order
49	Spine	4	d=85mm, L=160mm	Order
50	Pad	1	200x65x30mm	Order
51	Guard	1		Order
52	Pad	1	200x45x20mm	Order
53	Bracket	1		Order
54	Cover	1		Order
55	Cover	1	L=160mm	Order
56	T-branch	2	L=50mm	Order
57	Cover	1		Order
58	Bushing	1	D=330mm, L=73mm	Order
59	Bushing	1	D=180mm, L=155mm	Order
60	Stop	1		Order
61	Ring	1	D=95mm, L=10mm	Order
62	Bushing	1	D=180mm, L=55mm	Order
63	Ring	1	D=380mm, L=40mm	Order
64	Ring	1	D=278mm, L=35mm	Order
65	Ring	1		Order
66	Ring	1		Order
67	Nut	1	D=300mm, L=40mm	Order
68	Flange	1	D=225mm, L=41mm	Order
69	Ring	1		Order
70	Gear	1	d=366mm, m=3,⠀z=120	Order
71	Cover	1		Order
72	Bracket	1		Order
73	Housing	1	130x85x21mm	Order
74	Cover	1	d=160mm, L=45mm	Order
75	Screw	1	L=1040mm, Tr⠀60x8	Order
76	Flag	1		Order
77	Bushing	1	D=80mm, L=156mm	Order
78	Cover	1	D=95mm, L=15mm	Order
79	Shaft	1	L=190mm, d=40mm	Order
80	Gear	1	D=78mm, L=40mm, m=3,⠀z=24	Order
81	Flange	1	D=129mm, L=20mm	Order
82	Spacer	1		Order
83	Sleeve	1	D=130mm, L=74mm	Order
84	Shaft-gear	1	d=78mm, L=121mm, m=2,⠀z=37	Order
85	Bushing	1	D=70mm, L=40mm	Order
86	Spacer	1		Order
87	Drive dog	1	D=72mm, L=51mm	Order
88	Spring	1		Order
89	Nut	1	D=40mm, L=15mm	Order
90	Shaft	1	L=294mm, d=32mm	Order
91	Ring	1		Order
92	Spacer	1		Order
93	Gear	1	d=300mm, L=68mm	Order
94	Ring	1	D=110mm, L=10mm	Order
