MEASURING UNIT FOR WHEEL TURNING LATHES RT905F3, RT905F1 AND THEIR MODIFICATIONS

VIEW 1

No; Spare part; Quantity;Note; ;

1; Base ;1;; Order link=#rec477592549 2; Sheet ;1;; Order link=#rec477592549 3; Insert ;1;; Order link=#rec477592549 4; Compensator;1;; Order link=#rec477592549 5; Ring;1;; Order link=#rec477592549 6; Bracket;1;; Order link=#rec477592549 7; Cross slide;1;; Order link=#rec477592549 8; Guideway ;1;;Order link=#rec477592549 9; Spacer ;1;;Order link=#rec477592549 10; Holding block ;1;;Order link=#rec477592549 11; Measuring roller;1;Roller d=80mm;Order link=#rec477592549 12; Console;1; ;Order link=#rec477592549 13; Box;1; ;Order link=#rec477592549 14; Hydraulic cylinder;1;;Order link=#rec477592549 15; Axle ;1;;Order link=#rec477592549

No; Spare part; Quantity;

16; Suspension skirt ;1; Order link=#rec477592549 17; Screw ;1; Order link=#rec477592549 18; Axle;1; Order link=#rec477592549 19; Spacer ;1; Order link=#rec477592549 20; Spacer ;1; Order link=#rec477592549 21; Spacer ;1; Order link=#rec477592549 22; Door ;1; Order link=#rec477592549 23; Compensator ;1;Order link=#rec477592549 24; Axle ;1;Order link=#rec477592549 25; Angle bar ;1;Order link=#rec477592549 26; Plate ;1;Order link=#rec477592549 28; Bracket ;1;Order link=#rec477592549 29; Angle bar ;1;Order link=#rec477592549 30; Bracket;1;Order link=#rec477592549 31; Sensor ;1;Order link=#rec477592549 32; Bracket ;1;Order link=#rec477592549 33; Axle;1;Order link=#rec477592549
