HYDRAULIC DRIVE PIECES FOR WHEEL TURNING LATHES RT905F3, RT905F1 AND THEIR MODIFICATIONS

VIEW 1

No; Spare part; Quantity;Note; ;

1; Pad;1;65х90х35; Order link=#rec477761349 2; Pad;1;65х90х30; Order link=#rec477761349 3; Angle piece ;2;; Order link=#rec477761349 4; Flange ;3;D=150mm, L=27mm; Order link=#rec477761349 5; Plunger;3;D=110mm, L=50mm; Order link=#rec477761349 6; Ring;;;Order link=#rec477761349 7; Flange ;3;D=110mm, L=14mm; Order link=#rec477761349 8; Cover;9;;Order link=#rec477761349 9; Flange;3;d=150mm, L=18mm;Order link=#rec477761349 10; Bushing;3;d=55mm, L=79mm;Order link=#rec477761349 11; Pillar ;3;L=307mm, d=47mm;Order link=#rec477761349 12; Plunger;3; ;Order link=#rec477761349 13; Strip link=https://en.stankoartel.com/photos#rt905_kulachki_zazhima_kolesnoy_pari;3; ;Order link=#rec477761349 14; Ring;3;D=110mm, L=24mm;Order link=#rec477761349 15; Spacer;3;d=50mm, L=5mm;Order link=#rec477761349

No; Spare part; Quantity;Note; ;

16; Cylinder housing;3;d=110mm; Order link=#rec477761349 17; Cover;3;; Order link=#rec477761349 18; Strip;3;; Order link=#rec477761349 19; Slide link=https://en.stankoartel.com/photos#rt905_polzushka_povodka_zazhima_kolesnoy_pari;3;; Order link=#rec477761349 20; Screw;3;L=45mm; Order link=#rec477761349 21; Shaft;3;d=60mm, L=276mm; Order link=#rec477761349 22; Strip ;3;; Order link=#rec477761349 23; Strip;6;;Order link=#rec477761349 24; Strip;6;;Order link=#rec477761349 25; Wedge;3;;Order link=#rec477761349 26; Screw;6;;Order link=#rec477761349
