1; Cover; 1;; Order link=#rec477670224
2; Cover; 1;; Order link=#rec477670224
3; Cover ;1;d=150mm, L=58mm; Order link=#rec477670224
4; Ring;1;; Order link=#rec477670224
5; Flange;1;d=195mm, L=30mm;Order link=#rec477670224
6; Shaft;1;d=45mm, L=350mm; Order link=#rec477670224
7; Bushing;1;L=70mm, D=50mm, d=40,5mm; Order link=#rec477670224
8; Half clutch;1;d=100mm, L=95mm;Order link=#rec477670224
9; Spring ;8;;Order link=#rec477670224
10; Ring;1;;Order link=#rec477670224
11; Compensating ring;1;L=630mm;Order link=#rec477670224
12; Gear;1;d=88mm, L=60mm, m=4,⠀z=20;Order link=#rec477670224
13; Ring;1; ;Order link=#rec477670224
14; Flange;1;d=120mm, L=18mm;Order link=#rec477670224
15; Compensating ring;1;;Order link=#rec477670224
16; Shaft ;1;d=40mm, L=200mm;Order link=#rec477670224
17; Gear;1;d=80mm, L=50mm, m=4,⠀z=18;Order link=#rec477670224
18; Spacer ;1;;Order link=#rec477670224
19; Shaft;1;d=150mm, L=85mm, m=5,⠀z=28;Order link=#rec477670224
20; Insert;3;;Order link=#rec477670224
21; Gear;1;d=268mm, L=60mm, m=4,⠀z=65;Order link=#rec477670224
22; Gear;1;d=296mm, L=79mm, m=4,⠀z=72;Order link=#rec477670224
23; Clutch;1;d=70mm, L=140mm;Order link=#rec477670224
24; Nut;1;D=120mm, L=120mm, Tr⠀85x12;Order link=#rec477670224
25; Lead screw;1;L=926mm, Tr⠀85x12;Order link=#rec477670224
26; Flange;1;d=160mm, L=21mm;Order link=#rec477670224
27; Half ring;2;d=95mm, L=10mm;Order link=#rec477670224
28; Spacer;2;d=125mm, L=40,5mm;Order link=#rec364751839
29; Gear;1;d=90mm, L=20mm, m=2,⠀z=43;Order link=#rec477670224
30; Nut ;1;;Order link=#rec477670224
31; Housing ;1;;Order link=#rec477670224
