HEADSTOCK FOR LATHES 1N65 (1M65, DIP500, 165), RT117, RT317 AND#NBSP;THEIR MODIFICATIONS

VIEW 1

No; Spare part; Quantity;Note; ;

1; Flange ;1; ; Order link=#rec469038063 2; Electromagnetic clutch; 1;;Order link=#rec469038063 3; Cover; 1;;Order link=#rec469038063 4; Gear ; 1;m=4,5, z=21; Order link=#rec469038063 5; Gear; 1;m=4, z=49; Order link=#rec469038063 6; Shaft;1;L=522mm; Order link=#rec469038063 7; Shaft;1;; Order link=#rec469038063 8; Pulley;1;;Order link=#rec469038063 9; Gear;1;m=3,5, z=32;Order link=#rec469038063 10; Gear;1; m=3,5, z=54;Order link=#rec469038063 11; Gear;1; m=4, z=21;Order link=#rec469038063 12; Gear;1; m=4, z=35;Order link=#rec469038063 13; Gear;1; m=5, z=36;Orderlink=#rec469038063 14; Gear;1;m=4, z=35;Order link=#rec469038063 15; Gear;1;m=6, z=18;Order link=#rec469038063 16; Gear;1;m=4, z=42;Order link=#rec469038063 17; Fork;1;;Order link=#rec469038063 18; Gear;1;m=5, z=48;Order link=#rec469038063 19; Fork;1;;Order link=#rec469038063 20; Axle;1;L=623mm, D=35mm;Order link=#rec469038063 21; Shaft-gear;1;L=505mm, m=6, z=20;Order link=#rec469038063 22; Shaft;1;L=1255mm;Order link=#rec469038063 23; Gear block;1;;Order link=#rec469038063 24; Filter;3;;Order link=#rec469038063 25; Filter;3;;Order link=#rec469038063 26; Flange;1;D=370mm;Order link=#rec469038063 27; Center;1;L=340mm;Order link=#rec469038063 28; Nut;1;d=135mm;Order link=#rec469038063 29; Bushing;1;L=204mm, D=135mm, d=100mm;Order link=#rec469038063 ; Spindle;1;;Order link=#rec469038063 30; Half ring;1;;Order link=#rec469038063 31; Nut;1;D=290mm;Order link=#rec469038063 32; Bushing;1;L=162mm, d=200mm;Order link=#rec469038063 33; Nut;1;d=270mm;Order link=#rec469038063 34; Nut;1;d=272mm;Order link=#rec469038063 35; Gear;1;m=5, z=24;Order link=#rec469038063 36; Gear;1;m=5, z=60;Order link=#rec469038063 37; Gear;1;m=5, z=75;Order link=#rec469038063 38; Gear block;1;;Order link=#rec469038063 39; Gear;1;m=4,5, z=59;Order link=#rec469038063 40; Gear;1;m=5, z=36;Order link=#rec469038063 41; Gear block;1;;Order link=#rec469038063 42; Shaft ;1;L=532mm;Order link=#rec469038063 43; Bushing;1;L=50mm, D=140mm, d=85mm;Order link=#rec469038063 44; Nut;1;;Order link=#rec469038063 45; Gear;1;m=2, z=134;Order link=#rec469038063 46; Gear;1;m=5, z=50;Order link=#rec469038063

No; Spare part; Quantity;Note; ;

1; Gear segment;1;m=2, z=50; Order link=#rec469038063 2; Rack; 1;L=332mm, m=2; Order link=#rec469038063 3; Shaft; 1;L=935mm;Order link=#rec469038063 4; Cup ;1;; Order link=#rec469038063

No; Spare part; Quantity;Note; ;

1; Rack ; 1;L=120mm, m=2; Order link=#rec469038063 2; Gear segment;2;m=2, z=10; Order link=#rec469038063 3; Shaft;2;L=650mm; Order link=#rec469038063 4; Cup;1;; Order link=#rec469038063 5; Hub ;1;d=155mm;Order link=#rec469038063 6; Gear;1;m=2, z=23;Order link=#rec469038063 7; Shaft ;1; L=243mm;Order link=#rec469038063 8; Lever;1;;Order link=#rec469038063 9; Slide block;1; ;Order link=#rec469038063

No; Spare part; Quantity;Note; ;

1; Fork ; 1;; Order link=#rec469038063 2; Shaft;1;L=462mm; Order link=#rec469038063 3; Gear;1;m=4, z=21; Order link=#rec469038063 4; Adapter;1;; Order link=#rec469038063 5; Nut ;1;;Order link=#rec469038063 6; Gear;1;m=5, z=50;Order link=#rec469038063 7; Gear;1;m=5, z=40;Order link=#rec469038063 8; Shaft;1; L=593mm;Order link=#rec469038063 9; Shaft-rack;1;L=485mm, m=2;Order link=#rec469038063 10; Gear;1;m=3, z=38;Order link=#rec469038063 11; Gear;1;m=3, z=57;Order link=#rec469038063 12; Fork; 1;; Order link=#rec469038063 13; Axle;1;L=523mm;Order link=#rec469038063 14; Fork; 1;; Order link=#rec469038063 15; Axle;1;L=525mm;Order link=#rec469038063 16; Fork; 1;; Order link=#rec469038063 17; Axle;1;L=610mm;Order link=#rec469038063 18; Gear;1;m=4, z=21; Order link=#rec469038063
