FEED GEARBOX FOR LATHES 1N65 (1M65, DIP500, 165), RT117, RT317 AND THEIR MODIFICATIONS

VIEW 1

No; Spare parts; Quantity;Note; ;

1; Gear;1; m=2,75, z=28; Order link=#rec468983941 2; Flange; 1;; Order link=#rec468983941 3; Flange; 1;;Order link=#rec468983941 4; Flange; 1;d=130mm; Order link=#rec468983941 5; Shaft; 1;L=290mm; Order link=#rec468983941 6; Eccentric;1;; Order link=#rec468983941 7; Gear;1;; Order link=#rec468983941 8; Gear;1;m=3, z=37;Order link=#rec468983941 9; Gear;1;m=2,5, z=68;Order link=#rec468983941 10; Gear;1; m=3, z=55;Order link=#rec468983941 11; Gear;1; m=3,5, z=45;Order link=#rec468983941 12; Shaft;1; L=447mm;Order link=#rec468983941 13; Gear;1; m=2,75, z=57;Order link=#rec468983941 14; Gear;1;m=2,5, z=52;Order link=#rec468983941 15; Gear;1;m=2,75, z=49;Order link=#rec468983941 16; Gear;1;m=2,75, z=52;Order link=#rec468983941 17; Gear;1;m=2,75, z=54;Order link=#rec468983941 18; Gear;1;m=2,5, z=57;Order link=#rec468983941 19; Gear block;1;;Order link=#rec468983941 20; Gear block;1;;Order link=#rec468983941 21; Gear;1;;Order link=#rec468983941 22; Shaft;1;;Order link=#rec468983941 23; Gear block;1;;Order link=#rec468983941 24; Shaft-gear;1;L=293mm, m=2,75, z=26;Order link=#rec468983941 25; Flange;1;;Order link=#rec468983941 26; Bushing;1;D=115mm, d=105mm, L=78mm;Order link=#rec468983941 27; Clutch;1;;Order link=#rec468983941 28; Flange;1;;Order link=#rec468983941 29; Shaft;1;;Order link=#rec468983941 30; Gear;1;m=2,75, z=67;Order link=#rec468983941 31; Gear block;1;;Order link=#rec468983941 32; Gear;1;m=2,5, z=51;Order link=#rec468983941 33; Gear;1;m=2,5, z=34;Order link=#rec468983941 34; Shaft;1;;Order link=#rec468983941 35; Gear;1;;Order link=#rec468983941 36; Gear;1;m=2,5, z=44;Order link=#rec468983941 37; Gear block;1;;Order link=#rec468983941 38; Gear block;1;;Order link=#rec468983941 39; Gear block;1;;Order link=#rec468983941 40; Gear block;1;;Order link=#rec468983941 41; Shaft;1;;Order link=#rec468983941

No; Spare part; Quantity;Note; ;

42; Fork;1; ; Order link=#rec468983941 43; Fork; 1;; Order link=#rec468983941 44; Screw; 2;L=50mm;Order link=#rec468983941 45; Axle; 2;L=68mm; Order link=#rec468983941 46; Lever; 2;; Order link=#rec468983941 47; Draw;1;L=575mm;Order link=#rec468983941 48; Fork;1;; Order link=#rec468983941

No; Spare part; Quantity;Note; ;

49; Former; 1;; Order link=#rec468983941 50; Axle; 1;L=138mm; Order link=#rec468983941 51; Flange;1;L=138mm; Order link=#rec468983941 52; Disk;2;; Order link=#rec468983941 53; Cover ;1;;Order link=#rec468983941 54; Gear;1;m=2, z=67;Order link=#rec468983941 55; Axle;1; L=70mm;Order link=#rec468983941 56; Cover;1;;Order link=#rec468983941 57; Gear;1; m=2, z=67;Order link=#rec468983941 58; Former;1;;Order link=#rec468983941
