SPINDLE STOCK FOR LATHES 16R25 (16R25P), SA562 AND THEIR MODIFICATIONS

VIEW 1

No; Spare part; Quantity;Note; ;

1; Gear;1; ; Order link=#rec470506599 2; Flange of 12th axle; 1;D=123mm, d=48mm, L=74mm; Order link=#rec470506599 3; Shaft of 12th axle;1; d=38mm, L=289mm, 8⠀splines;Order link=#rec470506599 4; Strip ; 1;; Order link=#rec470506599 5; Axle of 13th axle; 1;L=222mm; Order link=#rec470506599 6; Shaft of 8th axle;1;d=36mm, L=341mm; Order link=#rec470506599 7; Stop of 8th axle;1;d=52mm, L=40mm; Order link=#rec470506599 8; Spacer of 13th axle;2;;Order link=#rec470506599 9; Gear;1;d=60mm, L=45mm, m=2,25,⠀z=25;Order link=#rec470506599 10; Gear of 8th axle;1;d=103mm, L=48mm, m=2,25,⠀z=44;Order link=#rec470506599 11; Spacer;1;d=47mm, L=80mm;Order link=#rec470506599 12; Gear of 8th axle;1;d1=155mm, L=16mm, m=2,5,⠀z=60, d2=141mm, L=68mm, m=3,⠀z=46;Order link=#rec470506599 13; Locator;1; ;Order link=#rec470506599 14; Spindle;1; L=965mm, Flange⠀d=290mm ;Order link=#rec470506599 15; Nut;1;D=136mm, d=120mm;Order link=#rec470506599 16; Grease interseptor;1;;Order link=#rec470506599 17; Cup;1;D=90mm, d=38mm, L=32mm;Order link=#rec470506599 18; Shaft of 2nd axle;1;d=32mm, L=268mm;Order link=#rec470506599 19; Cup of 2nd axle;1;D=62mm, d=38mm, L=28mm;Order link=#rec470506599 20; Gear;1;d1=129mm, L1=37mm, m=2,25,⠀z=56, d2=95mm, L2=108mm, m=2,25,⠀z=51;Order link=#rec470506599 21; Friction shaft;1;L=512mm;Order link=#rec470506599 22; Pulley;1;D=235mm, d=45mm, L=79mm;Order link=#rec470506599 23; Flange of 1st axle;1;D=123mm, d=60mm, L=18mm;Order link=#rec470506599 24; Spacer;1;D=54mm, d=45mm, L=48mm;Order link=#rec470506599 25; Flange of 1st axle;1;D=175mm, d=85mm, L=88mm;Order link=#rec470506599 26; Flange;1; d=108mm, L=45mm;Order link=#rec470506599 27; Shaft of 4th axle;1;;Order link=#rec470506599 28; Disk;2;d=92mm, 8⠀splines;Order link=#rec470506599 29; Disk;2;d=92mm, 8⠀splines;Order link=#rec470506599 30; Disk;21;d=92mm, 8⠀splines;Order link=#rec470506599 31; Nut of 1st axle;2;d=92mm, L=20,5mm;Order link=#rec470506599 32; Disk;2;d=92mm, 8⠀splines;Order link=#rec470506599 33; Disk;18;d=109mm, 4⠀splines;Order link=#rec470506599 34; Gear;1;d=117mm, L=81mm, m=2,25,⠀z=50;Order link=#rec470506599 35; Gear;1;d=85mm, L=48mm, m=2,25, z=36;Order link=#rec470506599 36; Shaft of 7th axle;1;d=25mm, L=135mm, d=25mm, L=135mm;Order link=#rec470506599 37; Clutch;1;d=71mm, L=40mm, 4 splines;Order link=#rec470506599 38; Rocker;1;;Order link=#rec470506599 39; Rod of 1st axle;1;d=22mm, L=206mm;Order link=#rec470506599 40; Prismatic key;1;L=70mm;Order link=#rec470506599 41; Bushing of 10th axle;1;;Order link=#rec470506599 42; Shaft-rack of 10th axle;1;L=396,5mm, m=2,5;Order link=#rec470506599 43; Gear;1;⠀⠀d1=141mm,⠀⠀ L1= 38mm, m=3,⠀z=45, d2=210mm, L2=17,5mm, m=3,⠀z=69;Order link=#rec470506599 44; Plug;1;;Order link=#rec470506599 45; Thrust flange;2;d=89,5mm, L=12mm;Order link=#rec470506599 46; Shaft of 4th axle;1;d=45mm, L=369mm;Order link=#rec470506599 47; Cup;2;D=110mm, d=90mm, L=50;Order link=#rec470506599 48; Shaft of 5th axle;1;d=50mm, L=370mm;Order link=#rec470506599 49; Block of 5th axle;1;⠀⠀ d1=92mm,⠀⠀ L1= 85mm, m=3,5,⠀z=24, d2=214,5mm, L2=28mm, m=3,⠀z=68;Order link=#rec470506599 50; Flange;1;D=270mm, d=155mm, L=29,5;Order link=#rec470506599 51; Gear;1;d=339mm, L=92mm, m=3,5,⠀z=96;Order link=#rec470506599 52; Gear;1;d=214mm, L=90mm, m=2;Order link=#rec470506599 53; Gear;1;d=174mm, L=75mm, m=2;Order link=#rec470506599 54; Nut;1;D=162mm, 8⠀splines;Order link=#rec470506599 55; Bushing;1;D=142, d=129, L=38,5mm;Order link=#rec470506599 56; Gear;1;d=155mm, L=63mm, m=2,5;Order link=#rec470506599 57; Flange;1;D=230mm, d=140,5mm;Order link=#rec470506599 58; Flange;1;D=246mm, d=151mm, L=40mm;Order link=#rec470506599 59; Housing;1;;Order link=#rec470506599 60; Cylindrical pin;1;L=38mm;Order link=#rec470506599 61; Gear;1;d1=92,5mm, L1=28mm, m=2,25,⠀z=39,⠀ d2= 81mm, L2=47mm, m=2,25,⠀z=34;Order link=#rec470506599 62; Gear;1;d=70mm, L=37mm, m=2,25,⠀z=29;Order link=#rec470506599 63; Gear;1;d=51mm, L=41mm, m=2,25,⠀z=21;Order link=#rec470506599 64; Gear;1;d=90mm, L=45,5, m=2,25, z=38;Order link=#rec470506599 65; Gear;1;d=141mm, L=68mm, m=3,⠀z=45;Order link=#rec470506599 66; Gear;1; d1=90mm, L1=75mm, m=2,25,⠀z=38, d2=128mm, L2=21mm, m=2,25,⠀z=55;Order link=#rec470506599 67; Gear of 4th axle;1;d=144mm, L=50mm, m=3,⠀z=45;Order link=#rec470506599

No; Spare part; Quantity;Note; ;

68; Bracket;1; ; Order link=#rec470506599 69; Handle; 1;; Order link=#rec470506599 70; Bushing;1;D=30mm, d=23mm, L=23mm;Order link=#rec470506599 71; Shaft of 17th axle; 1;d=22mm, L=353mm; Order link=#rec470506599 72; Formed plate; 1;; Order link=#rec470506599 73; Roller;1;; Order link=#rec470506599 74; Fork;1;; Order link=#rec470506599 75; Gear of 17th axle ;1;d=116mm, L=45mm, m=2,⠀z=56;Order link=#rec470506599 76; Slide block;1;;Order link=#rec470506599 77; Gear;1;d=116mm, L=26mm, m=2,⠀z=56;Order link=#rec470506599 78; Slide block;2;32x17x12;Order link=#rec470506599 79; Finger ;1;;Order link=#rec470506599 80; Finger ;1; ;Order link=#rec470506599 81; Handle ;2;;Order link=#rec470506599 82; Shaft of 18th axle;1;d=20mm, L=246mm;Order link=#rec470506599 83; Bushing ;2; d=29mm, L=64mm;Order link=#rec470506599 84; Lever;1;;Order link=#rec470506599

No; Spare part; Quantity;Note; ;

85; Shaft of 19th axle;1;d=20mm, L=126mm; Order link=#rec470506599 86; Lever ; 1;; Order link=#rec470506599 87; Slide block;1;34x16x5,6;Order link=#rec470506599 88; Finger; 1;; Order link=#rec470506599 89; Cover; 1;; Order link=#rec470506599 90; Fork ;1;; Order link=#rec470506599

No; Spare part; Quantity;Note; ;

91; Shaft;1; d=25mm, L=172mm; Order link=#rec470506599 92; Bushing; 1;D=44mm, d=25mm, L=93,5mm; Order link=#rec470506599 93; Gear sector ;1;m=2,5, z=35;Order link=#rec470506599 94; Handle; 2;; Order link=#rec470506599 95; Shaft of 20th axle; 1;d=25mm, L=156mm; Order link=#rec470506599 96; Collet;1;Flange⠀d=95mm, L=105; Order link=#rec470506599 97; Fixing ring ;1;; Order link=#rec470506599 98; Handle pad;1;d=95mm, L=30mm;Order link=#rec470506599 99; Guideway of 9th axle;1;d=26mm, L=415mm;Order link=#rec470506599 100; Draw of 14th axle;1;d=20mm, L=315mm;Order link=#rec470506599 101; Fork;1;;Order link=#rec470506599 102; Gear sector;1;m=2, z=48;Order link=#rec470506599 103; Fork;1; ;Order link=#rec470506599 104; Cup;1;d=35mm, L=22mm;Order link=#rec470506599 105; Rack;1;L=84mm, m=2;Order link=#rec470506599 106; Gear;1;d=44mm, L=48mm, m=2,⠀z=28;Order link=#rec470506599 107; Axle of 21st axle;1;d=16mm, L=95mm;Order link=#rec470506599 108; Gear sector;1;;Order link=#rec470506599 109; Bushing;1;D=60mm, d=40mm, L=50mm;Order link=#rec470506599 110; Axle of 23d axle;1;d=16mm, L=95mm;Order link=#rec470506599 111; Cam;1;d=95mm, L=30mm;Order link=#rec470506599 112; Gear;1;d=44mm, L=62mm, m=2,⠀z=20;Order link=#rec470506599 113; Rack;1;L=94mm, m=2;Order link=#rec470506599 114; Lever;1;;Order link=#rec470506599 115; Block of 4th axle;1;d1=218mm, L=18mm, m=3,5,⠀z=60, d2=102mm, L=108mm, m=3,⠀z=34;Order link=#rec470506599
